Foundation Construction Train

New and special civil-engineering technology for railway construction

Highest track availability and short shut-down times, challenging geographies and confined spaces demand know-how, experience and high-performance as well as approved special civil-engineering technology for railway construction.

The global market leader in railway cranes, Kirow Ardelt, together with RTG Rammtechnik (a specialist in vibration, piling, and pressing works from the BAUER Maschinen Group), has developed the high-performance track foundation train for HERING and the rail market. With its special rigging procedures, tool logistics, high foundation performance, quality, and speed, this rail-mounted carrier adapts special foundation engineering methods to railway applications. It ensures the safe, cost-effective, and project-specific implementation of your requirements.

Track foundations with equipment by HERING

Vibration-free drilling of holes with diameters of up to 1350 mm
MR 105 V (SilentVibro) vibrator for the high-frequency vibrating of sheet-piling profiles of lengths of up to 15 metres
HRS 5 hydraulic hammer for pile driving lengths of up to 12,20 metres
MPU 660 sheet-piling press or MPZ for pressing sheet pilings, Z-profiles, U-profiles and light profiles of up to 15 metres in length

Foundation Construction Train: The Revolution!

References

FIELDS OF APPLICATION – WITHOUT CONSTRUCTION ROAD

Realisation of bored piles using the Kelly drilling method for overhead line masts, signal brackets, noise barriers, etc.
Vibrating / pressing of sheet piling for securing excavations and stabilising railway embankments as well as installing girders for Berlin shoring, etc.
Driving in of concrete piling and casing pipes using the HRS5 hydraulic hammer
Installation of vibro-replacement stone columns for ground improvements in or near tracks (VIPAC method)

PERSPECTIVELY:

Production of bored piles using the rigid-cast-in-place method
Boring of cased and overlapping piles for bridge foundations and overlapping bored pile walls (front-of-wall method)
Realisation of single columns / diaphragm walls using the cutter-soil-mixing (CSM) and CSM DH methods as ground-improvement measures
Down-the-hole (DTH) hammer for drilling in rock

Foundation Construction Train - details:

Rail-mounted carrier equipment
Leader for use with special civil-engineering tools (vibrator, sheet-piling press, hydraulic hammer, kelly drilling equipment, etc.)
Comprehensive system consisting of a carrier unit, flat-bed carriage for storing the leader and additional flat-bed carriage for transporting and setting up attachments
Extends up to 9,50 metres from the track axis
Use in superelevations of up to 160 mm
Hydraulic rams for support distances of up to four metres from the track axis
360° swivelling around the upper carriage axis
Operation that keeps the opposite track free: maximum protrusion of upper carriage from the track axis is 1.55 metres
High foundation-laying performances, quality and speed

Existing heavy-duty rail-mounted machinery <> Foundation Construction Train
